Description
Main Technical Specification:
| Function | Compact Type |
| Level Range | 4, 6, 8, 10,12,20,30m |
| Accuracy | 0.5% |
| Resolution | 3mm or 0.1% |
| Display | LCD Display |
| Analog Output | Two Wire 4～20mA/250Ω Load |
| Relay Output | No |
| Power Supply | Standard 24VDC |
| Environmental Temperature | Transmitter -20～+60℃，Sensor -20～+80℃ |
| Communication | No |
| Protection Class | Transmitter IP65, Sensor IP68 |
| Cable | No |
| Probe Installation | Based on the level range |
Model Selection
| Measure Range |
| QTLM-4 0-4m
QTLM-6 0-6m QTLM-8 0-8m QTLM-12 0-12m QTLM-20 0-20m QTLM-30 0-30m |
| Ex Class |
| P Standard Type(Non ex-proof)
I Intrinsically safe (Exia IIB T6 Ga) |
| Energy Transducer Material/Process Temperature/Protection Grade |
| A ABS/(-40-75)℃/IP67
B PVC/(-40-75)℃/IP67 C PTFE/(-40-75)℃/IP67 |
| Process Connection/Material |
| G Thread
D Flange /PP |
| Electronic Unit |
| 2 4-20mA/24V DC /HART Two Wire |
| Shell / Protection Grade |
| L Aluminum / IP67 |
| Cable Entry |
| M M20*1.5
N 1/2’’ NPT |
| Programmer/Display |
| A With Display |
